12 | PRODUCT DATA
MULTI V IV Outdoor Unit Engineering Manual
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
©
/*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
GENERAL DATA
$5816HULHV+HDW3XPS2XWGRRU8QLW6SHFL¿FDWLRQV
Table 3: Dual-Frame 208-230V Heat Pump Units, continued.
Combination Unit Model Number
24.0 Ton
ARUN288BTE4
26.0 Ton
ARUN313BTE4
28.0 Ton
ARUN337BTE4
Individual Component Model Numbers
ARUN144BTE4 +
ARUN144BTE4
ARUN144BTE4 +
ARUN168BTE4
ARUN168BTE4 +
ARUN168BTE4
Cooling Performance
Nominal Cooling Cap. (Btu/h)
1
288,000 312,000 336,000
Rated Cooling Cap. (Btu/h)
2
274,000 296,000 320,000
Heating Performance
Nominal Heating Cap. (Btu/h)
1
324,000 351,000 378,000
Rated Heating Cap. (Btu/h)
2
308,000 334,000 361,000
Operating Range
Cooling (°F DB)
3
14 to 122 14 to 122 14 to 122
Heating (°F WB)
-13 to +61 -13 to +61 -13 to +61
Compressor
Inverter Quantity
HSS DC Scroll x 4 HSS DC Scroll x 4 HSS DC Scroll x 4
Oil/Type
PVE/FVC68D PVE/FVC68D PVE/FVC68D
Fan (Top Discharge)
Type
Propeller (BLDC) Propeller (BLDC) Propeller (BLDC)
Motor Output (kW) x Qty.
0.60 x 2 + 0.60 x 2 0.60 x 2 + 0.60 x 2 0.60 x 2 + 0.60 x 2
Motor/Drive
Brushless Digitally Controlled/Direct
Operation Range (RPM)
Cooling
0 - 1,100 0 - 1,100 0 - 1,100
Heating
80 - 1,100 80 - 1,100 80 - 1,100
Maximum Air Volume (CFM)
20,400 20,400 20,400
Unit Data
Refrigerant Type
R410A R410A R410A
Refrigerant Control/Location
EEV/Indoor Unit EEV/Indoor Unit EEV/Indoor Unit
Min. to Max. No. Indoor Units/System
4
1 - 45 1 - 52 1 - 55
Sound Pressure dB(A)
5
62.5 62.5 62.5
Net Unit Weight (lbs.)
628 + 628 628 + 628 628 + 628
Shipping Weight (lbs.)
661 + 661 661 + 661 661 + 661
Communication Cables
6,7
2 x 18 2 x 18 2 x 18
Heat Exchanger
Material and Fin Coating
Copper Tube/Aluminum Fin and GoldFin™/Hydrophilic
Rows/Fins per inch
3/14 3/14 3/14
Piping
8
Liquid Line Conn. (in., OD)
1/2 + 1/2 Braze 1/2 + 5/8 Braze 5/8 + 5/8 Braze
Vapor Line Conn. (in., OD)
1-1/8 + 1-1/8 Braze 1-1/8 + 1-1/8 Braze 1-1/8 + 1-1/8 Braze
Factory Charge lbs. of R410A
23.6 + 23.6 23.6 + 23.6 23.6 + 23.6
1
Nominal capacity applied with non-ducted indoor units, and is rated 0 ft. above sea level with 25 ft.
of refrigerant line per indoor unit and a 0 ft. level difference between outdoor and indoor units. All capaci-
ties are net with a Combination Ratio between 95–105%.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF
wet bulb (WB) and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Nominal heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and
59ºF wet bulb (WB) and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
2
Rated capacity is certified under AHRI Standard 1230. See www.ahrinet.org for information.
3
Cooling range with Low Ambient Baffle Kit (sold separately) is -9.9°F to +122°F.
4
The System Combination Ratio must be between 50–130%.
5
Sound pressure levels are tested in an anechoic chamber under ISO Standard 3745.
6
All communication cable to be minimum 18 AWG, 2-conductor, stranded, shielded, and must comply
with applicable local and national codes. Ensure the communication cable is properly grounded at the
master unit only. Do not ground the ODU-IDU communication cable at any other point.
7
Power wiring cable is field provided and must comply with the applicable local and national codes. See
page 31 for detailed electrical data.
8
Refer to the Refrigerant Piping section of this manual for correct line sizing. Contractor must use LG
manufactured Y-Branch and Header Kits only. Designer must verify refrigerant piping design configura-
tion using LG’s computerized refrigerant piping (LATS Multi V) software to validate the pipe design.
