PRODUCT DATA | 31
Product Data
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
©
/*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
Nom.
Tons
Unit Model
Nos.
Compressor (Comp.)
Condenser Fan
Motor(s)
MCA MOCP RFA
Comp.
Qty.
Motor Amps
Fan
Qty.
Amps
Motor RLA (Ea.)
FLA (Ea.)
Frame Frame Frame
1231 2 3 1 2 3
Frame
123
Frame
123
Comp.
A
Comp.
B
Comp.
A
Comp.
B
Comp.
A
Comp.
B
6.0 ARUN072BTE4 1 17.0 - - - - - 1 4.0 - - 25.3 - - 40 - - 35 - -
8.0 ARUN096BTE4 1 27.3 - - - - - 2 6.0 - - 40.1 - - 60 - - 50 - -
10.0 ARUN121BTE4 1 27.4 - - - - - 2 6.0 - - 40.3 - - 60 - - 50 - -
12.0 ARUN144BTE4 2 19.0 19.0 - - - - 2 6.0 - - 48.8 - - 60 - - 60 - -
14.0 ARUN168BTE4 2 20.7 20.7 - - - - 2 6.0 - - 52.5 - - 70 - - 70 - -
16.0 ARUN192BTE4 2 17.0 - 27.4 - - - 3 4.0 6.0 - 25.3 40.3 - 40 60 - 35 50 -
18.0 ARUN216BTE4 3 17.0 - 19.0 19.0 - - 3 4.0 6.0 - 25.3 48.8 - 40 60 - 35 60 -
20.0 ARUN240BTE4 3 27.3 - 19.0 19.0 - - 4 6.0 6.0 - 40.1 48.8 - 60 60 - 50 60 -
22.0 ARUN264BTE4 3 27.4 - 19.0 19.0 - - 4 6.0 6.0 - 40.3 48.8 - 60 60 - 50 60 -
24.0 ARUN288BTE4 4 19.0 19.0 19.0 19.0 - - 4 6.0 6.0 - 48.8 48.8 - 60 60 - 60 60 -
26.0 ARUN313BTE4 4 20.7 20.7 19.0 19.0 - - 4 6.0 - - 48.8 52.5 - 60 70 - 60 70 -
28.0 ARUN337BTE4 4 20.7 20.7 20.7 20.7 - - 4 6.0 6.0 - 52.5 52.5 - 70 70 - 70 70 -
26.0 ARUN312BTE4 4 17.0 - 27.3 - 19.0 19.0 5 4.0 6.0 6.0 25.3 40.1 48.8 40 60 60 35 50 60
28.0 ARUN336BTE4 4 27.3 - 27.3 - 19.0 19.0 6 6.0 6.0 6.0 40.1 40.1 48.8 60 60 60 50 50 60
30.0 ARUN360BTE4 4 27.3 - 27.4 - 19.0 19.0 6 6.0 6.0 6.0 40.1 40.3 48.8 60 60 60 50 50 60
32.0 ARUN384BTE4 5 27.3 - 27.2 17.0 27.2 17.0 6 6.0 6.0 6.0 40.1 57.0 57.0 60
80* 80* 50 80 80
34.0 ARUN408BTE4 5 27.4 - 27.2 17.0 27.2 17.0 6 6.0 6.0 6.0 40.3 57.0 57.0 60 80* 80* 50 80 80
36.0 ARUN432BTE4 6 27.2 17.0 27.2 17.0 27.2 17.0 6 6.0 6.0 6.0 57.0 57.0 57.0 80* 80* 80* 80 80 80
38.0 ARUN456BTE4 6 27.2 17.0 27.2 17.0 27.2 17.0 6 6.0 6.0 6.0 57.0 57.0 57.0 80* 80* 80* 80 80 80
40.0 ARUN480BTE4 6 27.2 17.0 27.2 17.0 27.2 17.0 6 6.0 6.0 6.0 57.0 57.0 57.0 80* 80* 80* 80 80 80
42.0 ARUN504BTE4 6 27.2 17.0 27.2 17.0 27.2 17.0 6 6.0 6.0 6.0 57.0 57.0 57.0 80* 80* 80* 80 80 80
ARUN Series Heat Pump Outdoor Units
ELECTRICAL DATA
Table 23: 208-230V, 60Hz, 3-Phase Heat Pump Units.
For component model nos. see the specification tables on p. 10-14.
Voltage tolerance is ±10%.
Maximum allowable voltage unbalance is 2%.
MCA = Minimum Circuit Ampacity.
Maximum Overcurrent Protection (MOCP) is calculated as follows: (Largest motor FLA x 2.25) + (Sum of
other motor FLA) rounded down to the nearest standard fuse size.
RFA = Recommended Fuse Amps.
*SCCR rating: 5kA RMS Symmetrical.
