Table 9: Triple-Frame 460V Heat Pump Units.
GENERAL DATA
$5816HULHV+HDW3XPS2XWGRRU8QLW6SHFL¿FDWLRQV
Combination Unit Model
Number
26.0 Ton
ARUN312DTE4
28.0 Ton
ARUN336DTE4
30.0 Ton
ARUN360DTE4
32.0 Ton
ARUN384DTE4
34.0 Ton
ARUN408DTE4
Individual Component Model
Numbers
1
ARUN072DTE4 +
ARUN096DTE4 +
ARUN144DTE4
ARUN096DTE4 +
ARUN096DTE4 +
ARUN144DTE4
ARUN096DTE4 +
ARUN121DTE4 +
ARUN144DTE4
ARUN096DTE4 +
ARUN145DTE4 +
ARUN145DTE4
ARUN121DTE4 +
ARUN145DTE4 +
ARUN145DTE4
Cooling Performance
Nominal Cooling Cap. (Btu/h)
2
312,000 336,000 360,000 384,000 408,000
Rated Cooling Cap. (Btu/h)
3
296,000 320,000 342,000 366,000 390,000
Heating Performance
Nominal Heating Cap. (Btu/h)
2
351,000 351,000 405,000 432,000 459,000
Rated Heating Cap. (Btu/h)
3
334,000 334,000 387,000 412,000 437,000
Operating Range
Cooling (°F DB)
4
14 to 122 14 to 122 14 to 122 14 to 122 14 to 122
Heating (°F WB)
-13 to +61 -13 to +61 -13 to +61 -13 to +61 -13 to +61
Compressor
Inverter Quantity
HSS DC Scroll x 4 HSS DC Scroll x 4 HSS DC Scroll x 4 HSS DC Scroll x 5 HSS DC Scroll x 5
Oil/Type
PVE/FVC68D PVE/FVC68D PVE/FVC68D PVE/FVC68D PVE/FVC68D
Fan (Top Discharge)
Type
Propeller (BLDC) Propeller (BLDC) Propeller (BLDC) Propeller (BLDC) Propeller (BLDC)
Motor Output (kW) x Qty.
0.75 + 0.60 x 2
+ 0.60 x 2
0.60 x 2 + 0.60 x 2
+ 0.60 x 2
0.60 x 2 + 0.60 x 2
+ 0.60 x 2
0.60 x 2 + 0.60 x 2
+ 0.60 x 2
0.60 x 2 + 0.60 x 2
+ 0.60 x 2
Motor/Drive
Brushless Digitally Controlled/Direct
Operating
Range (RPM)
Cooling
0 - 1,100 0 - 1,100 0 - 1,100 0 - 1,100 0 - 1,100
Heating
80 - 1,100 80 - 1,100 80 - 1,100 80 - 1,100 80 - 1,100
Maximum Air Volume (CFM)
27,450 29,900 29,900 30,250 30,250
Unit Data
Refrigerant Type
R410A R410A R410A R410A R410A
Refrigerant Control/Location
EEV/Indoor Unit EEV/Indoor Unit EEV/Indoor Unit EEV/Indoor Unit EEV/Indoor Unit
Min. to Max. No. Indoor Units/
System
5
1 - 52 1 - 55 1 - 58 1 - 61 1 - 64
Sound Pressure dB(A)
6
63.8 63.9 63.9 64.1 64.1
Net Unit Weight (lbs.)
430 + 540 + 628 540 + 540 + 628 540 + 540 + 628 540 + 628 + 628 540 + 628 + 628
Shipping Weight (lbs.)
452 + 573 + 661 573 + 573 + 661 573 + 573 + 661 573 + 661 + 661 573 + 661 + 661
Communication Cables
7,8
2 x 18 2 x 18 2 x 18 2 x 18 2 x 18
Heat Exchanger
Material and Fin Coating
Copper Tube/Aluminum Fin and GoldFin™/Hydrophilic
Rows/Fins per inch
3/14 3/14 3/14 3/14 3/14
Piping
9
Liquid Line Conn. (in., OD)
3/8 + 3/8 + 1/2 Braze 3/8 + 3/8 + 1/2 Braze 3/8 + 1/2 + 1/2 Braze 3/8 + 5/8 + 5/8 Braze 1/2 + 5/8 + 5/8 Braze
Vapor Line Conn (in., OD)
3/4 + 7/8 + 1-1/8 Braze 7/8 + 7/8 + 1-1/8 Braze 7/8+1-1/8+1-1/8 Braze 7/8+1-1/8+1-1/8 Braze 1-1/8+1-1/8+1-1/8 Braze
Factory Charge lbs. of R410A
16.9 + 23.6 + 23.6 23.6 + 23.6 + 23.6 23.6 + 23.6 + 23.6 23.6 + 23.6 + 23.6 23.6 + 23.6 + 23.6
1
ARUN145BTE4/ARUN145DTE4, ARUN169BTE4/ARUN169DTE4 frames are ONLY for use in large
capacity triple frame combinations. They cannot be used as stand alone models or in a dual frame
combination. These frames ARE NOT interchangeable with ARUN144BTE4/ARUN144DTE4, ARUN-
168BTE4/ARUN168DTE4 single frame models.
2
Nominal capacity applied with non-ducted indoor units, and is rated 0 ft. above sea level with 25 ft.
of refrigerant line per indoor unit and a 0 ft. level difference between outdoor and indoor units. All
capacities are net with a Combination Ratio between 95–105%.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF
wet bulb (WB) and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Nominal heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and
59ºF wet bulb (WB) and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
3
Rated capacity is certified under AHRI Standard 1230. See www.ahrinet.org for information.
4
Cooling range with Low Ambient Baffle Kit (sold separately) is -9.9°F to +122°F.
5
The System Combination Ratio must be between 50–130%.
6
Sound pressure levels are tested in an anechoic chamber under ISO Standard 3745.
7
All communication cable to be minimum 18 AWG, 2-conductor, stranded, shielded, and must comply
with applicable local and national codes. Ensure the communication cable is properly grounded at the
master unit only. Do not ground the ODU-IDU communication cable at any other point.
8
Power wiring cable is field provided and must comply with the applicable local and national codes. See
page 32 for detailed electrical data.
9
Refer to the Refrigerant Piping section of this manual for correct line sizing. Contractor must use LG
manufactured Y-Branch and Header Kits only. Designer must verify refrigerant piping design configura-
tion using LG’s computerized refrigerant piping (LATS Multi V) software to validate the pipe design.
