LG Multi IV User Manual

Indoor Units (IDU)
Indoor Units
UNIT NOMENCLATURE
B3 = Ducted (low static - bottom return)
B4 = Ducted (low static - bottom return)
B8 = Ducted (high static)
BG = Ducted (high static)
BH = Ducted (high static)
BR = Ducted (high static)
CE = Floor Standing (small frame)
CF = Floor Standing (large frame)
L1 = Ducted (low static)
L2 = Ducted (low static)
L3 = Ducted (low static)
NJ = Vertical/Horizontal Air Handling Unit
NK = Vertical/Horizontal Air Handling Unit
SB = Wall Mounted / Art Cool™ Mirror
SC = Wall Mounted / Art Cool Mirror
SF = Art Cool Gallery
SV = Wall Mounted
TT = 1-Way Ceiling Cassette
TU = 1-Way Ceiling Cassette
TL = 2-Way Ceiling Cassette
TM = 4-Way Ceiling Cassette
TN = 4-Way Ceiling Cassette
TP = 4-Way Ceiling Cassette
TQ = 4-Way Ceiling Cassette
TR = 4-Way Ceiling Cassette
VE = Convertible Surface Mounted
VJ = Ceiling Suspended
INTRODUCTION | 5
Introduction
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
©
/*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
ARN U 07 3 TN C
Generation
2 = Second
4 = Fourth
A = Second, Revision A
Electrical Ratings
3 = 208–230V/60Hz/1Ph
05 = 5,000 Btu/h
07 = 7,000 Btu/h
09 = 9,000 Btu/h
12 = 12,000 Btu/h
15 = 15,000 Btu/h
18 = 18,000 Btu/h
24 = 24,000 Btu/h
28 = 28,000 Btu/h
30 = 30,000 Btu/h
36 = 36,000 Btu/h
42 = 42,000 Btu/h
48 = 48,000 Btu/h
54 = 54,000 Btu/h
76 = 76,000 Btu/h
96 = 96,000 Btu/h
Type
U = DC Inverter Heat Pump
Family
ARN = Multi V Indoor Unit
(Refrigerant R410A)
Feature
A, C, L, R = Standard*
G = Low Static
U = Uncased
H/
1P
1P
h
h
Indoor Unit Nominal Capacity
Model
4
*Filter accessories are available separately. Always follow all local, state, and national building codes with the use of this or any
product.
