Table 14: Triple-Frame 208-230V Heat Recovery Units.
GENERAL DATA
$58%6HULHV+HDW5HFRYHU\2XWGRRU8QLW6SHFL¿FDWLRQV
Combination Unit Model Number
26.0 Ton
ARUB312BTE4
28.0 Ton
ARUB336BTE4
30.0 Ton
ARUB360BTE4
32.0 Ton
ARUB384BTE4
34.0 Ton
ARUB408BTE4
Individual Component Model Numbers
1
ARUB072BTE4 +
ARUB096BTE4 +
ARUB144BTE4
ARUB096BTE4 +
ARUB096BTE4 +
ARUB144BTE4
ARUB096BTE4 +
ARUB121BTE4 +
ARUB144BTE4
ARUB096BTE4 +
ARUB145BTE4 +
ARUB145BTE4
ARUB121BTE4 +
ARUB145BTE4 +
ARUB145BTE4
Cooling Performance
Nominal Cooling Cap. (Btu/h)
2
312,000 336,000 360,000 384,000 408,000
Rated Cooling Cap. (Btu/h)
3
296,000 320,000 342,000 366,000 390,000
Heating Performance
Nominal Heating Cap. (Btu/h)
2
351,000 378,000 405,000 432,000 459,000
Rated Heating Cap. (Btu/h)
3
334,000 361,000 387,000 412,000 437,000
Operating Range
Cooling (°F DB)
4
14 to 122 14 to 122 14 to 122 14 to 122 14 to 122
Heating (°F WB)
-13 to +61 -13 to +61 -13 to +61 -13 to +61 -13 to +61
Synchronous—Cooling Based (°F DB)
14 to 81 14 to 81 14 to 81 14 to 81 14 to 81
Synchronous—Heating Based (°F DB)
14 to 61 14 to 61 14 to 61 14 to 61 14 to 61
Compressor
Inverter Quantity
HSS DC Scroll x 4 HSS DC Scroll x 4 HSS DC Scroll x 4 HSS DC Scroll x 5 HSS DC Scroll x 5
Oil/Type
PVE/FVC68D PVE/FVC68D PVE/FVC68D PVE/FVC68D PVE/FVC68D
Fan (Top Discharge)
Type
Propeller (BLDC) Propeller (BLDC) Propeller (BLDC) Propeller (BLDC) Propeller (BLDC)
Motor Output (kW) x Qty.
0.75 + 0.60 x 2
+ 0.60 x 2
0.60 x 2 + 0.60 x 2
+ 0.60 x 2
0.60 x 2 + 0.60 x 2
+ 0.60 x 2
0.60 x 2 + 0.60 x 2
+ 0.60 x 2
0.60 x 2 + 0.60 x 2
+ 0.60 x 2
Motor/Drive
Brushless Digitally Controlled/Direct
Operating
Range (RPM)
Cooling
0 - 1,100 0 - 1,100 0 - 1,100 0 - 1,100 0 - 1,100
Heating
80 - 1,100 80 - 1,100 80 - 1,100 80 - 1,100 80 - 1,100
Maximum Air Volume (CFM)
27,450 29,900 29,900 30,250 30,250
Unit Data
Refrigerant Type
R410A R410A R410A R410A R410A
Refrigerant Control/Location
EEV/Indoor Unit EEV/Indoor Unit EEV/Indoor Unit EEV/Indoor Unit EEV/Indoor Unit
Min. to Max. No. Indoor Units/System
5
1 - 52 1 - 55 1 - 58 1 - 61 1 - 64
Sound Pressure dB(A)
6
63.8 63.9 63.9 64.1 64.1
Net Unit Weight (lbs.)
430 + 540 + 628 540 + 540 + 628 540 + 540 + 628 540 + 672 + 672 540 + 672 + 672
Shipping Weight (lbs.)
452 + 573 + 661 573 + 573 + 661 573 + 573 + 661 573 + 705 + 705 573 + 705 + 705
Communication Cables
7,8
2 x 18 2 x 18 2 x 18 2 x 18 2 x 18
Heat Exchanger
Material and Fin Coating
Copper Tube/Aluminum Fin and GoldFin™/Hydrophilic
Rows/Fins per inch
3/14 3/14 3/14 3/14 3/14
Piping
9
Liquid Line Connection (in., OD)
3/8+3/8+1/2 Braze 3/8+3/8+1/2 Braze 3/8+1/2+1/2 Braze 3/8+5/8+5/8 Braze 1/2+5/8+5/8 Braze
Low Pressure Vapor Line Conn (in., OD)
3/4+7/8+1-1/8 Braze 7/8+7/8+1-1/8 Braze 7/8+1-1/8+1-1/8 Braze 7/8+1-1/8+1-1/8 Braze 1-1/8+1-1/8+1-1/8 Braze
High Pressure Vapor Line Conn (in, OD)
5/8+3/4+7/8 Braze 3/4+3/4+7/8 Braze 3/4+3/4+7/8 Braze 3/4+7/8+7/8 Braze 3/4+7/8+7/8 Braze
Factory Charge lbs. of R410A
16.9 + 23.6 + 23.6 23.6 + 23.6 + 23.6 23.6 + 23.6 + 23.6 23.6 + 23.6 + 23.6 23.6 + 23.6 + 23.6
1
ARUB145BTE4/ARUB145DTE4, ARUB169BTE4/ARUB169DTE4 frames are ONLY for use in
large capacity triple frame combinations. They cannot be used as stand alone models or in a dual
frame combination. These frames ARE NOT interchangeable with ARUB144BTE4/ARUB144DTE4,
ARUB168BTE4/ARUB168DTE4 single frame models.
2
Nominal capacity applied with non-ducted indoor units, and is rated 0 ft. above sea level with 25 ft.
of refrigerant line per indoor unit and a 0 ft. level difference between outdoor and indoor units. All
capacities are net with a Combination Ratio between 95–105%.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF
wet bulb (WB) and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Nominal heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and
59ºF wet bulb (WB) and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
3
Rated capacity is certified under AHRI Standard 1230. See www.ahrinet.org for information.
4
Cooling range with the Low Ambient Baffle Kit (sold separately) is -9.9°F to +122°F and is achieved only
when all indoor units are operating in cooling mode. Does not impact synchronous operating range.
5
The System Combination Ratio must be between 50–130%.
6
Sound pressure levels are tested in an anechoic chamber under ISO Standard 3745.
7
All communication cable to be minimum 18 AWG, 2-conductor, stranded, shielded, and must comply
with applicable local and national codes. Ensure the communication cable is properly grounded at the
master unit only. Do not ground the ODU-IDU communication cable at any other point.
8
Power wiring cable is field provided and must comply with the applicable local and national codes. See
page 33 for detailed electrical data.
9
Refer to the Refrigerant Piping section of this manual for correct line sizing. Contractor must use LG
manufactured Y-Branch and Header Kits only. Designer must verify refrigerant piping design configuration
using LG’s computerized refrigerant piping (LATS Multi V) software to validate the pipe design.
