PRODUCT DATA | 33
Product Data
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
©
/*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
Table 25: 208-230V, 60Hz, 3-Phase Heat Recovery Units.
Nom.
Tons
Unit Model
Nos.
Compressor (Comp.)
Condenser Fan
Motor(s)
MCA MOCP RFA
Comp.
Qty.
Motor Amps
Fan
Qty.
Amps
Motor RLA (Ea.)
FLA (Ea.)
Frame Frame Frame
1231 2 3123
Frame
Frame
123
123
Comp.
A
Comp.
B
Comp.
A
Comp.
B
Comp.
A
Comp.
B
6.0 ARUB072BTE4 1 17.0 - - - - - 1 4.0 - - 25.3 - - 40 - - 35 - -
8.0 ARUB096BTE4 1 27.3 - - - - - 2 6.0 - - 40.1 - - 60 - - 50 - -
10.0 ARUB121BTE4 1 27.4 - - - - - 2 6.0 - - 40.3 - - 60 - - 50 - -
12.0 ARUB144BTE4 2 19.0 19.0 - - - - 2 6.0 - - 48.8 - - 60 - - 60 - -
14.0 ARUB168BTE4 2 20.7 20.7 - - - - 2 6.0 - - 52.5 - - 70 - - 70 - -
16.0 ARUB192BTE4 2 17.0 - 27.4 - - - 3 4.0 6.0 - 25.3 40.3 - 40 60 - 35 50 -
18.0 ARUB216BTE4 3 17.0 - 19.0 19.0 - - 3 4.0 6.0 - 25.3 48.8 - 40 60 - 35 60 -
20.0 ARUB240BTE4 3 27.3 - 19.0 19.0 - - 4 6.0 6.0 - 40.1 48.8 - 60 60 - 50 60 -
22.0 ARUB264BTE4 3 27.4 - 19.0 19.0 - - 4 6.0 6.0 - 40.3 48.8 - 60 60 - 50 60 -
24.0 ARUB288BTE4 4 19.0 19.0 19.0 19.0 - - 4 6.0 6.0 - 48.8 48.8 - 60 60 - 60 60 -
26.0 ARUB313BTE4 4 20.7 20.7 19.0 19.0 - - 4 6.0 - - 48.8 52.5 - 60 70 - 60 70 -
28.0 ARUB337BTE4 4 20.7 20.7 20.7 20.7 - - 4 6.0 6.0 - 52.5 52.5 - 70 70 - 70 70 -
26.0 ARUB312BTE4 4 17.0 - 27.3 - 19.0 19.0 5 4.0 6.0 6.0 25.3 40.1 48.8 40 60 60 35 50 60
28.0 ARUB336BTE4 4 27.3 - 27.3 - 19.0 19.0 6 6.0 6.0 6.0 40.1 40.1 48.8 60 60 60 50 50 60
30.0 ARUB360BTE4 4 27.3 - 27.4 - 19.0 19.0 6 6.0 6.0 6.0 40.1 40.3 48.8 60 60 60 50 50 60
32.0 ARUB384BTE4 5 27.3 - 27.2 17.0 27.2 17.0 6 6.0 6.0 6.0 40.1 57.0 57.0 60 80*
80* 50 80 80
34.0 ARUB408BTE4 5 27.4 - 27.2 17.0 27.2 17.0 6 6.0 6.0 6.0 40.3 57.0 57.0 60 80* 80* 50 80 80
36.0 ARUB432BTE4 6 27.2 17.0 27.2 17.0 27.2 17.0 6 6.0 6.0 6.0 57.0 57.0 57.0 80* 80* 80* 80 80 80
38.0 ARUB456BTE4 6 27.2 17.0 27.2 17.0 27.2 17.0 6 6.0 6.0 6.0 57.0 57.0 57.0 80* 80* 80* 80 80 80
40.0 ARUB480BTE4 6 27.2 17.0 27.2 17.0 27.2 17.0 6 6.0 6.0 6.0 57.0 57.0 57.0 80* 80* 80* 80 80 80
42.0 ARUB504BTE4 6 27.2 17.0 27.2 17.0 27.2 17.0 6 6.0 6.0 6.0 57.0 57.0 57.0 80* 80* 80* 80 80 80
ARUB Series Heat Recovery Outdoor Units
ELECTRICAL DATA
For component model nos. see the specification tables on p. 20-24.
Voltage tolerance is ±10%.
Maximum allowable voltage unbalance is 2%.
MCA = Minimum Circuit Ampacity.
Maximum Overcurrent Protection (MOCP) is calculated as follows: (Largest motor FLA x 2.25) + (Sum of
other motor FLA) rounded down to the nearest standard fuse size.
RFA = Recommended Fuse Amps.
*SCCR rating: 5kA RMS Symmetrical.
