User Manual 10H52192UM60 - Rev. 1 - 09/2011 45
Operator Control and Display Panel Liebert NX
Status/Alarm Explanation
Inverter in Setting The inverter starts up and is synchronized.
Rectifier in Setting The rectifier starts up and is synchronized.
Battery Room Alarm The temperature in the battery room is high and requires attention.
Battery Reverse Reconnect battery and check battery wiring.
Auto start After UPS shutdown at EOD, the inverter automatically starts when the mains supply is restored.
Rec Flash Update Rectifier software being updated.
Inv Flash Update Inverter software being updated.
Monitor Flash Update Monitoring software being updated.
Bypass Flash Update Bypass software being updated.
LBS abnormal LBS abnormal
