Lighthouse Worldwide Solutions ApexR3p User Manual

ApexRp Operators Manual
19 248083480-1 Rev 3
ApexR3p
Size Range
0.3 - 5.0 µm
Channel Thresholds
Standard 2-channel: 0.3, 0.5 μm
Standard 4-channel: 0.3, 0.5, 1.0, 5.0 μm
Optional 6-channel: 0.3, 0.5, 0.7, 1.0, 3.0, 5.0 μm
Flow Rate
1.0 CFM (28.3 LPM)
Counting Efficiency
50% (per ISO 21501-4)
Data Storage
Rotating Buffer, 3000 records
Light Source
Laser diode
Zero Count Level
<1 count/5 minutes (per ISO 21501-4)
Calibration
NIST Traceable
Communication Modes
MODBUS ASCII; MODBUS RTU; MODBUS TCP
Maximum Tubing Length
The sum of exhaust tubing length plus inlet tubing
length to ISO kinetic probe may not exceed 10 ft. (3.0 M)
Supporting Software
LMS Pharma/Pro v7.3 or higher, LMS Express 8.2 or
higher; LWS Instrument Setup Tool 1.4.XX or higher.
Power Supply
External power supply: 24 VDC, 5 A max draw
Enclosure
316L Stainless Steel, VHP compatible
Dimensions
6.65”(w) x 9.13”(h) x 4.75”(d) [16.89 x 23.19 x 12.06 cm]
Weight
6.3 lbs. (2.9 kg)
Operating Temp/RH
50° F to 104° F (10° C to 40° C) / 20% to 95% non-
condensing
Storage Temp/RH
14° F to 122° F (-10° C to 50° C) / Up to 98%
noncondensing
Table 2-4 ApexR3p Specifications
