ApexRp Operators Manual
43 248083480-1 Rev 3
Changing the Default Instrument Parameters
The main instrument parameters involved with the operation of the
ApexRp are Location, Sample Time and Hold Time. See Table
6-4.
Sample Time and Hold Time both use 2 registers, a high word and a
low word. If the desired value for any of these parameters is less than
or equal to 9 hours, 6 minutes and 7 seconds (32,767 seconds), then
only the low word register needs to be written with the value in
seconds.
The low word register for Sample Time is 40034.
The low word register for Hold Time is 40032.
Table 6-4 Instrument Parameters
Provides location ID for where data was recorded. State
Works in conjunction with 40032. Number of seconds to
wait between sample period. Max value is 359,999
which equals 99h 59m 59s.
Works in conjunction with 40034. Number of seconds to
sample. Max value is 86,399 which equals 23h 59m 59s.
