ApexRp Operators Manual
47 248083480-1 Rev 3
Table 6-8 Alarm Threshold Registers
Setting the Alarm Threshold Value
The Alarm Threshold Value is set in the low register of the channels.
Each channel has independent threshold value registers. Since any or
all channels can be enabled for alarms at any given time, each
threshold value applies to the corresponding channel. Setting a value
for channel 1 as 100 will not affect channel 2 setting of, say, 500. See
Table 6-9.
Table 6-9 Alarm Threshold Registers set to 1000
Threshold for Particle Channel 1 [high]
(smallest particle size starts here)
Threshold for Particle Channel 1 [low]
Threshold for Particle Channel 2 [high]
Threshold for Particle Channel 2 [low]
Threshold for Particle Channel 3 [high]
Threshold for Particle Channel 3 [low]
Threshold for Particle Channel 4 [high]
Threshold for Particle Channel 4 [low]
