4. Operation MX-FR Series Modular Matrix Frames – User's Manual 58
Supported Boards: MX-TPS-OB, -S, -A, MX-TPS2-OB-P, -AP, -SP; MX-4TPS2-4HDMI-OB, -A, -S, -P, -AP, -SP
Use the up ▲ and down ▼ buttons to select the parameter to be changed.
Use the left ◄ and right ► buttons to change the value.
The Signal mode can be set to DVI, HDMI or Auto mode. The Auto option sets
incoming signal. Use the left ◄ and right ► buttons to change the value.
The Encryption option sets the HDCP encryption on the output. The Auto
setting applies encryption when the incoming signal is encrypted. The
Always setting forces encryption on any incoming video signal. Use the left
◄ and right ► buttons to change the value. #hdcp
For detailed information about the HDCP modes, see the HDCP
Management section. #nosyncscreen #testpattern
The Test pattern generator makes it simple to test and troubleshoot video
hook-ups and displays. Use the left ◄ and right ► buttons to change the
value. On turns on, Off turns off the test pattern generator. If it is on, the
output gives a solid red, 480p video signal. (This is the default value.) In
the case of No signal mode, the output does not give any signal.
Three options can be selected for the resolutions of the TPG: 480p 60Hz,
576p 60Hz and Odd p. signal. Odd p. signal means the resolution of the test
(Input 1 for the input 1 and 2, Input 3 for input 3 and 4, and so on…) If there
is no video signal on the odd input, the generator gives 480p signal.
The pattern can be solid green, blue, black, white or black and white ramp and
chessboard or color bar. The cycle changes all the listed ones periodically.
The Audio mode settings are available in the case of the MX-TPS-OB-A and
MX-TPS-OB-S boards. It can be selected here which is embedded in the
forwarded HDMI signal: it can be set to No audio (A), HDMI audio passth. (B),
Embed from Ext (C), Deembed to Ext (D) or HDMI + deemb (E).
The DVI or HDMI 5V line can be controlled on an output port with the
PWR5V mode. If it is On, the 5VDC is always active. If it is Off, the port never
sends the 5 VDC. #power5v
ATTENTION! If the 5V line is off, sink devices do not send HotPlug
signal in most cases and their EDIDs will not be read.
Output 7 settings
~Signal mode ~
~<HDMI >~
Encryption
Output 7 settings
Auto
~ Encryption ~
~<Auto >~
Output 7 settings
Auto
~TPG mode ~
~<Off >~
Output 7 settings
Off
~TPG clk ~
~<Odd p. Signal >~
Output 7 settings
Color bar
~Audio mode ~
~<HDMI + deembed >~
Output 7 settings
HDMI + deembed
~PWR5V mode ~
~<Auto >~
The Auto mode means the port gives the 5V, but if the video signal changes (e.g. resolution), it turns off the
5V for 1 sec and turns it on again.
TIPS AND TRICKS: This mode is useful for sink devices that are not able to handle the changing of the
video signal properly.
The Analog Audio Output settings are available in the case of boards with
analog audio add-on ("-A" extension). The submenu contains the attributes
of the analog audio signal.
input (embed), the options are the
followings: volume, balance gain, phase (inversion), DC Filter.
In the case of output (deembed), the options are: volume, balance, bass,
treble, deemphasis, phase (inversion), DC Filter.
The TPS mode can be HDBaseT, Longreach, Automatic, RS232 only and
RS232+ETH only.
For detailed information about the TPS modes, see the TPS Link Modes
section.
The PoE setting (remote Power over Ethernet) is available only in the case
of TPS2 boards. Set the desired mode (enable/disable). #audio #analogaudio
#gain
Supported Boards: MX-HDMI-3D-OB, MX-HDMI-3D-OB-S,
MX-HDMI-3D-OB-A, MX-4TPS2-4HDMI-OB, -A, -S, -P, -AP, -SP,
MX-DVI-4K-OB #hdcp
Use the up ▲ and down ▼ buttons to select the parameter to be changed.
Use the left ◄ and right ► buttons to change the value.
The Signal mode can be set to DVI, HDMI or Auto mode. The Auto option sets
incoming signal. Use the left ◄ and right ► buttons to change the value.
The Encryption option sets the HDCP encryption on the output. The Auto
setting applies encryption when the incoming signal is encrypted. The
Always setting forces encryption on any incoming video signal. Use the left
◄ and right ► buttons to change the value. For detailed information about
the HDCP modes see the HDCP Management section.
The Test pattern generator makes it simple to test and troubleshoot video
hook-ups and displays. Use the left ◄ and right ► buttons to change the
value. On turns on, Off turns off the test pattern generator. If it is off, the
output gives a solid black, 480p video signal. (This is the default value.) In
the case of No signal mode, the output does not give any signal.
#nosyncscreen #testpattern
Output 7 settings
Audio mode
HDMI + deembed
~Analog Audio Inpu>>
Analog Audio Input~
~Volume ~
~< 0 dB >~
Balance
Output 7 settings
Analog Audio Input.
~TPS mode ~
~<HDBaseT >~
Input 17 settings
Automatic
~PoE ~
~<Disable >~
Output 3 settings
~Signal mode ~
~<HDMI >~
Encryption
Output 3 settings
~Encryption ~
~<Always >~
TPG mode
Output 3 settings
Auto
~TPG mode ~
~<on >~
