4. Operation MX-FR Series Modular Matrix Frames – User's Manual 59
Three options can be selected for the resolutions of the TPG: 480p 60Hz,
576p 60Hz and Odd p. signal. Odd p. signal means the resolution of the test
(Input 1 for the input 1 and 2, Input 3 for input 3 and 4, and so on…) If there
is no video signal on the odd input, the generator gives a 480p signal.
The pattern can be solid green, blue, black, white or black and white ramp and
chessboard or color bar. The cycle changes all the listed ones periodically.
The Audio mode settings are available in the case of the MX-HDMI-3D-OB-A
and MX-HDMI-3D-OB-S boards. It can be selected here which is embedded
in the forwarded HDMI signal: it can be set to No audio (A), HDMI audio
passth. (B), Embed from Ext (C), Deembed to Ext (D) or HDMI + deemb (E).
#power5v
The DVI or HDMI 5V line can be controlled on an output port with the
PWR5V mode. If it is On, the 5V DC is always active. If it is Off, the port never
sends the 5 V DC.
ATTENTION! If the 5V line is off, sink devices do not send HotPlug
signal in most cases and their EDIDs will not be read.
The Auto mode means the port gives the 5V, but if the video signal changes
(e.g. resolution), it turns off the 5V for 1 sec and turns it on again.
INFO: This mode is useful for sink devices that are not able to handle
the changing of the video signal properly.
The Analog Audio Output settings are available in the case of the MX-TPS-
OB-A board. The submenu contains the attributes of the analog audio
signal.
input (embed), the options are:
volume, balance, gain, phase (inversion), DC Filter.
In the case of output (deembed), the options are: volume, balance, bass, treble,
deemphasis, phase (inversion), DC Filter.
Output 3 settings
On
~TPG clk ~
~<Odd p. Signal >~
Output 3 settings
Odd p. Signal
~TPG pattern ~
~<Color bar >~
Output 3 settings
Audio mode
HDMI + deembed
~Analog Audio Inpu>>
Output 3 settings
HDMI + deembed
~PWR5V mode ~
~<Auto >~
Volume
0 dB
~Balance ~
~< 50 % >~
Analog Audio Input~
~Volume ~
~< 0 dB >~
Balance
Output 3 settings
Audio mode
HDMI + deembed
~Analog Audio Inpu>>
Supported Boards: MX-HDMI-OPT-OB-R-SC, MX-HDMI-OPT-OB-R-LC, MX-
HDMI-OPT-OB-R-ST, MX-HDMI-OPT-OB-R-NT
Use the up ▲ and down ▼ buttons to select the parameter to be changed.
Use the left ◄ and right ► buttons to change the value.
The Signal mode can be set to No change, DVI or HDMI. The No change option
does not convert the output signal into DVI or HDMI video. Use the left ◄
and right ► buttons to change the value. #hdcp
The Encryption option sets the HDCP encryption on the output. The Auto
setting applies encryption when the incoming signal is encrypted. The
Always setting forces encryption on any incoming video signal. Use the left
◄ and right ► buttons to change the value. For detailed information about
the HDCP modes, see the HDCP Management section.
The Test pattern generator makes it simple to test and troubleshoot video
hook-ups and displays. Use the left ◄ and right ► buttons to change the
value. On turns on, Off turns off the test pattern generator. If it is off, the
output gives a solid black, 480p video signal. (This is the default value.) In
the case of No signal mode the output does not give any signal.
#nosyncscreen #testpattern
Three options can be selected for the resolutions of the TPG: 480p 60Hz,
576p 60Hz and Odd p. signal. Odd p. signal means the resolution of the test
(Input 1 for the input 1 and 2, Input 3 for input 3 and 4, and so on…) If there
is no video signal on the odd input, the generator gives a 480p signal.
The pattern can be solid green, blue, black, white or black and white ramp and
chessboard or color bar. The cycle changes all the listed ones periodically.
The laser on each output port can be enabled or disabled. Disabling
unused laser outputs can lengthen their lifespan. Use the left ◄ and right
► buttons to change the value. The remote serial communication feature
can be enabled or disabled.
RS-232
Command Transmission section), enable the Serial Passthrough option.
recommended to disable this feature if not used.
Supported board: MX-AUDIO-OB-A
Use the up ▲ and down ▼ buttons to select the parameter to be changed.
Use the left ◄ and right ► buttons to change the value.
The submenu contains the attributes of the analog audio output signal. The available options are: volume,
balance, bass, treble, deemphasis, phase (inversion).
Output 16 settings
~Signal mode ~
~<HDMI >~
Encryption
Output 16 settings
~Encryption ~
~<Always >~
TPG mode
Output 16 settings
Auto
~TPG mode ~
~<on >~
Output 3 settings
On
~TPG clk ~
~<Odd p. Signal >~
Output 3 settings
Odd p. Signal
~TPG pattern ~
~<Color bar >~
Output 16 settings
~Laser enable ~
~< On >~
Output 17 settings
Color bar
Laser enable [*]
~Serial passthr[*] ~
Output 1 settings
~Volume ~
~< 0 dB >~
Balance
