Actuator with IC and Endstop Signals
I/O specifications
Input/Output Specification Comments
White Signal GND Only for mechanical slide
potentiometer and analogue
feedback
Max� 1 mA
For correct wiring of power GND and
Signal GND, see: Correct Wiring of
Power GND and Signal GND for IC
Ready signal Only for Single Hall and PWM
Max� 10 mA
To Next Page
