Actuator with IC and Endstop Signals
I/O specifications
Input/Output Specification Comments
Violet Mechanical slide potentiometer:
0-10 V
Slide potentiometer, 10 kohm
1 kohm = 0 mm stroke
11 kohm = 100 mm stroke
The maximum effect: 0�1 W
Max� 100 mm stroke
Linearity: ± 20 %
Minimum lifetime: 15,000 cycles
Average lifetime: 40,000 cycles
Max� current output: 1 mA
Analogue feedback:
0-10 V (Option F)
0�5-4�5 V (Option K)
Tolerances: +/- 0�2 V
Max� current output: 1 mA
Ripple max�: 200 mV
Transaction delay: 100 ms
Linear feedback: 0�5 %
Single Hall sensor:
2 pulses (Option L)
4 pulses (Option N)
Actuator mm per
pulse
12xLxx-1 1 mm
12xNxx-1 0�5 mm
12xLxx-2 2 mm
12xNxx-2 1 mm
12xLxx-3 3 mm
12xNxx-3 1�5 mm
Max� current output: 12 mA
Output = input -1 V
Dual Hall - 10 pulses XOR (Option S)
Movement per single Hall pulse:
Actuator mm per
pulse
12xSxx-1
0�2 mm
12xSxx-2
0�4 mm
12xSxx-3
0�6 mm
Frequency:
Frequency is 14-26 Hz on Single Hall
output depending on load�
Every pulse is “ON” for minimum 3 ms�
Higher voltage on the motor can result
in shorter pulses�
Max� current output: 12 mA
Output = input -1 V
Min� on time: 2�5 ms
None (Option D) Not available with feedback or
endstop out�
