LINET Image 3 B Instructions For Use And Technical Description

D9U001AM2-0101_06 19
6 Technical Specication
6.1 Applied parts type B
All the accesories the patient can reach are type B applied parts.
List of type B applied parts:
► ACP Attendant Control Panel
► Handset
► Satellite controller
► Siderails
► Head board and foot board
► Mattress support platform
6.2 Mechanical Specication
Parameter Value
Dimensions 220 cm x 110 cm
Siderail Height Above Mattress Support Platform 48 cm
Siderails Length 146 cm
Maximum Mattress Height 26 cm
Mattress Support Platform Dimensions (Mattress) 200 cm x 100 cm
Mattress Support Platform Extension 0 cm / 10 cm / 22 cm / 30,5 cm
Mattress Support Platform Height Adjustment 28 cm – 80 cm (85 cm - depending on congu-
ration)
Undercarriage Clearance 13 cm (15,5 cm - depending on conguration)
Castor Diameter 12,5 cm
Maximum Backrest Angle 70°
Maximum Thighrest Angle 34°
Ergoframe® 10 cm / 6 cm
Trendelenburg 14°
Antitrendelenburg position 14°
Bed Weight 160 kg
Maximum Lifting Pole Load 100 kg
Safe Working Load (including Mattress and Accessories) 320 kg
Maximum patient weight
Application environment 1, 2
Application environment 3, 5
255 kg
285 kg
6.3 Environment Conditions
Environmental Conditions - Operation
■ Ambient Temperature
■ Relative Humidity
■ Atmospheric Pressure
10 °C — 40 °C
30 % — 75 %
795 hPa — 1060 hPa
Environmental Conditions - Storage and Transport
■ Ambient Temperature
■ Relative Humidity
■ Atmospheric Pressure
-20°C — +50°C
20% — 90% (non-condensing)
795 hPa — 1060 hPa
