D9U001AM2-0101_06
35
12.1.1 Central STOP Button
The central STOP button 7 immediately interrupts all bed movements.
Pressing central STOP button 7 for at least 0.3 seconds immediately stops all electronic bed movements.
12.1.2 Activating GO Button
The GO button 18 activates the keypads on all control elements except the foot control.
A GO button is included on a number of different control elements. The function of the GO button is identical on all control ele-
ments. After pressing GO button 18, the keypad will remain active for 3 minutes. It is possible to control every function on the bed
except the locked functions. Pressing a function button will keep the keypad active for another 3 minutes.
It is necessary to activate the keypad again if the 3 minute period without pressing any function is passed.
12.1.3 Function Buttons
Function buttons 3, 4, 5 and 6 allow the setting of different positions, for example the height and tilt of the mattress support plat-
form, adjust individual mattress platform elements, etc.
NOTE: The bed can be stopped by pressing two different buttons even on two different controllers. If the press of the buttons is
longer than 0,5 second the bed will stop all the movements immediately.
To set a position:
► Activate the keypad by pressing the GO button.
► Press and hold the respective button until required position is reached.
12.1.4 Lock Buttons
Lock button 2 allows disabling individual functions on the Attendant Control Panel.
To disable functions:
► Activate the keypad by pressing the GO button 18.
► Press respective lock button.
The respective LED ashes to indicate the lock.
NOTE: The individual functions are locked in the central control panel, the satellite control and the handset.
To enable disabled functions:
► Activate the keypad by pressing the GO button.
► Press the respective lock button.
The respective LED goes out. The function is enabled.
12.1.5 Position Buttons
WARNING!
Risk of injury due to moving parts!
► Ensure that no body parts are trapped between moving parts of bed and mattress platform.
► Ensure that no persons or body parts are close to bed or accessories (e.g. infusion stand, lifting pole) when
mattress platform is moving
CAUTION!
Material damage due to moving parts!
► Ensure that no objects (e.g. cables) are trapped between moving parts of bed and mattress support platform.
► Ensure that no objects are close to bed or accessories (e.g. infusion stand, lifting pole) when mattress support
platform is moving.
The therapeutic and safety-related positions are pre-programmed. When a position is set, several parts of the bed and mattress
support platform will move simultaneously.
Programmed positions:
► Cardiac chair position
► Trendelenburg position
► CPR (resuscitation) position
