11 Manipulation
11.1 Siderails
WARNING!
Risk of injury, damaging or involuntary movement of the bed due to incorrect placement of accessories or
handset!
► Never place any accessories or handset on the siderails in the area where the integrated siderail controller is
located.
The split siderails are components of the bed. A pneumatic spring supports the operation of the split siderails. The nursing per-
sonnel are responsible for the siderails being folded up while the patient is in bed. The correct placement of handset is shown at
following picture.
WARNING!
Risk of injury when adjusting the bed!
► Ensure that there are no body parts between the mattress support platform elements and the mattress support
platform frame when adjusting the bed.
► Ensure that there are no body parts below the mattress support platform frame before adjusting the bed.
Fig. Siderails
11
3
3
2
MANIPULATION
To raise siderails up:
► Grab siderail by Siderail Handle (1).
► Pull siderail up until it latches. You will hear audible „click“.
To release siderails down:
► Grab siderail by Siderail Handle (1).
► Press upper edge of siderail inwards.
► Unlock siderail by pulling Siderail Release Handle (3) to yourself.
► Fold down siderail slowly.
1. Siderail Handle
2. Correct Placement of Handset
3. Siderail Release Handle
