Setting language of the Help Screen:
► Press icon 8 repeatedly until desired language is displayed.
New patient:
It is recommended to use New Patient function when replacing patients. The New Patient function is enabled when the bed is loa-
ded with at least 35 kg.
Button performs following functions:
■ Scales Taring (only if the scales are stabilized)
■ Deletes Scales history
■ Deletes ALT history
■ Deletes History of Backrest adjustment
■ Sets CLP with level 2 (only Symbioso)
■ Deletes Pressure Comfort Setting (only OptiCare)
■ Turns ON MCM
■ Turns ON Fowler Boost function (only Symbioso)
■ Turns OFF Sleep Mode (only Symbioso)
■ Sets MCM with HIGH level (only OptiCare)
Use the function as follows:
► Wait until the scales are stabilized.
► Press GO button.
► Press and hold icon 10 until it turns yellow.
► The Scales display is shown on LCD.
Scales have been tared, history deleted and it is possible to place new patient on the bed.
Logging out the mattress:
When replacing the integrated mattress (OptiCare or Symbioso) by a standard mattress, it is necessary to log out the integrated
mattress.
► Press and hold Mattress OFF Icon 9 until vertical bar timer runs to zero and mattress icon disappears.
NOTE Logging out OptiCare mattress or Symbioso mattress to use a standard mattress instead will disable the Manual CPR
pop-up menu.
11.5.5 Help Screen
Help Screen shows instructions for users.
Help Screen is available in Czech, English, Italian, French, Spanish, Swedish, Dutch, Brazilian Portuguese, Finnish, Danish and
German. Use Settings Screen to set a required language.
11.5.6 Pop-Ups
Pop-Up Meaning Required Action
Function locked. Unlock function if required!
Incorrectly inserted X-Ray Cassette
Holder.
Insert X-Ray Cassette Holder correctly!
GO Button not activated. Press GO Button!
Lateral Tilt disabled when siderail folded
down.
Raise siderail up to enable additional Lateral Tilting.
