1. Bed Picture
2. Inner Zone Icon
3. Outer Zone Icon
4. ON Icon (activation)
5. OFF Icon (deactivation)
6. PAUSE Icon
7. VOLUME Icon
8. Volume Levels (3 levels)
9. Patient Picture
Fig. Bed Exit Monitoring Screen (ON)
1
2
3
4
5 6 7
9
8
14.3 Control of Bed Exit Monitoring
14.4 Monitored Zone
Bed Exit Monitoring provides monitoring of Inner Zone or monitoring of Outer Zone.
Inner Zone covers the mattress support platform without margins around siderails, head board and foot board.
Outer Zone covers the mattress support platform up to the margins.
Monitoring of Inner Zone is set by default.
To set monitoring of Outer Zone:
► Press Outer Zone Icon (3).
To set monitoring of Inner Zone:
► Press Inner Zone Icon (2).
14.5 PAUSE
During PAUSE mode the Bed Exit Monitoring is temporarily interrupted and alarms are not activated.
PAUSE period is terminated automatically and the Bed Exit Monitoring is reactivated again when patient returns just to the selected
zone.
To PAUSE Bed Exit Monitoring:
► Press PAUSE Icon (6).
PAUSE Icon turns yellow and countdown timer (15 min) appears on the display above the PAUSE Icon.
After terminated PAUSE period when patient is in ordered position the Bed Exit Monitoring is reactivated again.
To extend the PAUSE period:
► Press PAUSE Icon (6) again to extend the countdown to 15 minutes period again.
To terminate the PAUSE period:
► Press ON Icon (4).
