D9U001ES1-0101_0834
CAUTION!
► Do not place objects on the undercarriage cover outside storage space!
► Respect dimensions of objects placed in storage space of the undercarriage cover!
► For information about objects intended for storage in the space of undercarriage cover follow chapter Accesso-
ries.
► press and hold Head End Lowering pedal and Foot End Lowering pedal at the same time until intended position is reached
If the horizontal position is required ensure this position was reached.
In order to eliminate a remaining longitudinal tilt use corresponding pedal.
10.3.5
Fig. Positions of Head End Lowering pedals
and Foot End Lowering pedals
