D9U001ES1-0101_0862
Fig. Oxygen Bottle Holder (at head end on the left) - posi-
tion 1
Fig. Oxygen Bottle Holder (at head end on the left) - position 2
13.8 X-Ray Cassette Holder (optional)
WARNING!
Respect maximum dimensions of x-ray cassettes!
► Maximum dimensions of any x-ray cassette for Adjustable X-Ray Cassette Holder are 47 cm x 46 cm x 2,2 cm!
► Maximum dimensions of any x-ray cassette for Fixed X-Ray Cassette Holder are 58 cm x 46 cm x 2,4 cm!
WARNING!
► Do not use any x-ray cassettes exceeding the Safe Working Load!
WARNING!
Prevent x-ray cassettes from being damaged!
► Do not leave any x-ray cassette in the Adjustable X-Ray Cassette Holder or in the Fixed X-Ray Cassette Holder if
X-Ray Examination should not be performed!
CAUTION!
Prevent x-ray images from being devalued!
► Take x-ray images when the bed is braked and no part of the bed is forced to move!
► Follow the instructions in the instructions for use how to use the Adjustable X-Ray Cassette Holder and the Fixed
X-Ray Cassette Holder!
WARNING!
► Accessory rail at head end is not compatible with both X-Ray Cassette Holders when Backrest is down!
► Accessory rail at foot end (only Sprint 100 with 2-part Mattress Support Platform) is not compatible with both X-
-Ray Cassette Holders!
► Both X-Ray Cassette Holders in the most remote position on the Backrest are not compatible with an oxygen
bottle on the undercarriage cover!
► Storage Space is not compatible with x-ray cassettes in both X-Ray Cassette Holders when Backrest is down!
