D9U001ES1-0101_08
49
► Make sure that Mattress Support Platform is in the highest position.
► Position upper part of C-arm above the patient.
The x-ray tube of the C-arm is located between the undercarriage and the Mattress Support Platform.
► Adjust position of siderails accordingly - depending on the C-arm position.
NOTE In some cases the bed may cause artifacts on the x-ray image. Do the patient risk assessment accordingly and evaluate the
positive eect on the in-bed examination versus impact of artifacts.
Fig. Space for the lower part of C-arm
44 cm88 cm
39 cm 32 cm
12 Mattress
CAUTION!
► In the case of other mattresses check maximum approved mattress dimensions (chapter Technical Specication)
and its specic shape.
Sprint 100 bed is designed for special passive mattresses from LINET portfolio.
SPRINT 100 PASSIVE MATTRESSES
Patient should not be transported on these mattresses from one place to another.
