LINET Sprint 100

D9U001ES1-0101_08 45
Fig. Control ring and hooks

► Ensure the right Foldable infusion stand is not extended.
► Grasp orange bar of the right Foldable infusion stand.
► Lift the right Foldable infusion stand up (1) to unlock it.
► Fold the right Foldable infusion stand down (2).
► Ensure the left Foldable infusion stand is not extended.
► Grasp orange bar of the left Foldable infusion stand.
► Lift the left Foldable infusion stand up (3) to unlock it.
► Fold the left Foldable infusion stand down (4).
To lift Foldable infusion stands up:
► Grasp orange bar of the left Foldable infusion stand.
► Lift the left Foldable infusion stand up.
► Check if the left Foldable infusion stand is locked in place.
► Grasp orange bar of the right Foldable infusion stand.
► Lift the right Foldable infusion stand up.
► Check if the right Foldable infusion stand is locked in place.
To extend Foldable infusion stand:
► Put control ring up (5).
► Extend the Foldable infusion stand by taking its telescopic part out.
To shorten Foldable infusion stand:
► Put control ring up (5).
► Insert the telescopic part into the Foldable infusion stand.

► Take a hook out (6).
6
55
Fig. Removable handles (front view)
Fig. Positions for Removable handles
11.7 Handles
Pair of handles is intended for bed transport.
The handles are located in head end corners or in foot end corners.
There are 3 types of the handles: removable, foldable or xed in their positions.
11.7.1 Removable handles
Removable handles can be removed by pulling them out of their place in corners of the bed on head end or on foot end.
