Linksys LAPAC1750PRO User Manual

51
Section 3: Configuring the Access Point
LAPAC1750PRO Access Point Software User Manual
Start Time The time when the radio or VAP will be operationally
enabled. The time is in HH:MM 24-hour format. The range
is <00-23>:<00-59>. The default is 00:00.
End Time The time when the radio or VAP will be operationally
disabled. The time is in HH:MM 24-hour format. The range
is <00-23>:<00-59>. The default is 00:00.
After you select a profile from the Select Profile field, the rules that have been
added to the selected profile appear in the table below the Rule Configuration
area. When you add a new rule to a profile, it appears in the table. Use the
Modify Rule and Remove Rule buttons to manage the rules associated with a
profile.
Use the buttons to perform the following tasks:
• Add: To add a scheduler profile, specify the name of the profile in the
appropriate field and click Add.
• Remove: To remove a scheduler profile, select it from the Select Profile field
in the Rule Configuration table and click Remove.
• Add Rule: After you configure the rule settings, click Add Rule to add the
rule to the selected profile.
• Modify Rule: To change an existing rule, select the rule, update the values
in the Rule Configuration area, and click Modify Rule.
• Remove Rule: To delete a rule from a profile, select the rule and click
Remove Rule.
• Save: After making any modifications, click Save to apply the changes and
to save the settings.
Scheduler Association
For a scheduler profile to take effect, you must associate it with at least one
radio or VAP interface. To associate the Scheduler profiles, select the Scheduler
Association tab in the Manage section. By default, there are no scheduler
profiles created, so no profile is associated to any radio or VAP. The scheduler
profile needs to be explicitly associated to a radio or VAP configuration. Only
one scheduler profile can be associated to any radio or VAP configuration;
however, a single profile can be associated to multiple radios or VAPs. If the
scheduler profile associated with a VAP or radio is deleted, then the associated
profile to the VAP or radio is removed implicitly. If the radio is operationally
disabled, then all the VAPs associated to that radio are also operationally
disabled irrespective of the VAP configuration.
Figure 29: Scheduler Association
The scheduler profiles need to be associated to a radio interface or the VAP
interface for applying the periodic rules to a specific radio or VAP.

Linksys LAPAC1750PRO Specifications

General

Modulation	-
VLAN support	Yes
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1750 Mbit/s
Internal	No
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Ethernet LAN (RJ-45) ports	2
Security algorithms	802.1x RADIUS, WEP, WPA, WPA2
Antenna gain level (max)	5.2 dBi
Input current	2 A
AC input voltage	12 V
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	238 mm
Width	247 mm
Height	43.3 mm
Weight	520 g
