Product Overview
Chapter 2
24-Port 10/100 + 2-Port 10/100/1000 Gigabit Advanced Smart Switch with 2 Combo SFPs
Back Panel
The console and power ports are located on the back
panel of the Switch.
Back Panel
Power The Power port is where you will
connect the AC power.
Console The Switch is equipped with a serial
port labeled Console (located on the back
of the switch) that allows you to connect to
a computer’s serial port (for configuration
purposes) using the provided serial cable. You
can use HyperTerminal to manage the Switch
using the console port.
Side Panel
The security slot is located on a side panel of the Switch.
Side Panel
SECURITY SLOT The security slot can be
utilized to attach a lock to the Switch.
