Lippert Components Ground Control 2.0 - Page 21

Rev:11.08.19 Page 21 CCD-0001573-08
Bottom of Jack Motor Override:
Tools needed:
⁄
” drive ratchet and extension,
⁄
” socket
1. Find the port on the bottom of the jack motor (Fig. 9A).
2. Remove the rubber plug (Fig. 10A).
3. Insert the 5/16” socket into the port (Fig. 11).
4. Turn override until the jack extends or retracts to desired position.
Fig. 11
Fig. 7
A
Fig. 8
Fig. 6
A
Fig. 10
A
Fig. 9
A
Top of Jack Motor Override:
Tools needed:
⁄
” drive ratchet and extension (no socket)
1. Find the port on the top of the jack motor (Fig. 6A).
2. Remove the rubber plug (Fig. 7A).
3. Insert the
⁄
” drive into the port (Fig. 8).
4. Turn override until the jack extends or retracts to desired position.
