Lippert Components Ground Control 2.0 User Manual

Rev:11.08.19 Page 74 CCD-0001573-08
Manual Override
NOTE: For ease of manual override it is recommended to unplug the power harness to the motor prior to
performing the manual override procedure.
A
A
B
A
NOTE: Use of a 12-18 volt cordless screw gun or pneumatic screw gun is acceptable to manually override
the jacks. If manual override is necessary there are two options for each style of jack.
NOTE: If the travel trailer is equipped with four C-Jacks, the override procedure is the same for the front
and rear.
2K or 3K C-Jack Motor Override:
Tools needed: A
⁄
” drive ratchet and extension, no socket.
1. Find the port on the jack gearbox (Fig. 38A).
2. Remove the rubber plug (Fig. 39A).
3. Insert the
⁄
” drive ratchet into the port.
4. Turn the override until the jack extends or retracts to desired position.
2K or 3K C- Jack Manual Override Nut:
Tools needed:
¾
" socket and ratchet
1. Locate the manual override nut (Fig. 38B).
2. Place
¾
" socket and ratchet over the manual override nut (Fig. 40A) and turn the override nut until the
jack extends or retracts to desired position.
Moving parts can pinch, crush or cut. Keep clear and use caution.
Do not use an impact screw gun to perform any of the override procedures,
as this may damage the motor
Fig. 38
Fig. 39 Fig. 40
