Lippert Components Ground Control 2.0 User Manual

Rev:11.08.19 Page 38 CCD-0001573-08
Manual Override
Top of Jack Motor Override:
Tools needed: 3/8” drive ratchet and extension (no socket)
1. Find the port on the top of the jack motor (Fig. 12A).
2. Remove the rubber plug (Fig. 13A).
3. Insert the 3/8” drive ratchet into the port (Fig. 14).
4. Turn the override until the jack extends or retracts to desired position.
Fig. 12
Fig. 13
A
Fig. 14
Fig. 15
Fig. 16
A
A
B
Bottom of Jack Motor Override:
Tools needed: 3/8” drive ratchet and extension, 5/16” socket
1. Find the port on the bottom of the jack motor (Fig. 12B).
2. Remove the rubber plug (Fig. 15A).
3. Insert the 5/16” socket into the port (Fig. 16).
4. Turn the override until the jack extends or retracts to desired position.

Lippert Components Ground Control 2.0 Specifications

General

Brand	Lippert Components
Model	Ground Control 2.0
Category	Lifting Systems
Language	English
