30
POWER INSTALLATION
Connect the Power
All LCR-II shipments typically include a 40' gray power cable (100', and 300' are also available) and a 7.5A fuse.
40’ GRAY POWER CABLE


power source as possible.
EPSON PRINTER POWER
Power must be supplied to the Epson printer as well. A 15' cable with a 12/24VDC converter (825001) for printer
power supply is also available. The red wire of this cable must be spliced into the red wire of the gray power cable on
the LCR-II side of the 7.5A fuse.
1. Route the gray power cable to the accessory panel. See
page 17.
2. Splice the red wire from the printer power cable into the
red wire of the gray power cable.
 
close to the direct power terminal connection in the
accessory panel and on the power side of the splice
made with the printer power cable.
Power Check



CPU board against the manual.
4. Connect the red wire to the direct power supply terminal
in the accessory panel.
 
reliable DC ground.
 
DC ground.
 
against the power cable.
To connect power to the LCR-II and the Epson printer:
Page 17 describes describe the best practices for routing the gray power cable to the truck cab’s accessory panel.
