31
POWER INSTALLATION
Gray Power Cable 40’ (81512)
EARTH/Blue (13)
GND/Black (12)
+12-24/Red (11)
7.5 A In-Line Fuse
Drain Wire
GROUND
Accessory Panel
Direct
Power
Supply
POWER J6
DC
11 12 13
Gray Power Cable
(see below)
Black Data Cable
7.5A In-Line Fuse
Black
Red
Red
Accessory Panel
Chassis or Reliable Ground
DC Ground
Power
Supply
Epson Printer Power Connections
LectroCount LCR-II Power Connections
