Lite-On Technology Corp.

Industrial Automation

1.2. Comparison of the product numbers

1.2.1. Description for the name plate

ISA-7 series servo drive

 Description for the name plate

Product number

Power specifications

Input power specifications

Output power

specifications

The firmware version

Serial number for production control
