Lite-On Technology Corp.
Industrial Automation
32
3.2. Basic block diagram of the server system
3.2.1. Models with the power equal to or below 200W (no built-in regenerative
resistor or fan)
AC
DC
M
Control
panel
P C
D
AC
DC
AC
DC
5V
15V
-15V
Current
feedback
U
V
W
Voltage
detection
24V
PWM drive
15V
Alarm
Regeneration
detection
ENC
L1
L2
R
S
T
CN2
CN3
CN5
CN1
DA
Analog output
monitoring
RS232/RS485
External speed
External torque
Position pulse
Digital I/O
Note: When power input in single phase, connect power cable to whichever 2 of RST.
