Chapter 2 Steps for Commissioning and Tuning
2.1. Notes
The user must pay attention to the following:
Do not pull the connecting line between the servo drive and motor tight.
The servo drive must be fastened at every securing spot.
The axle center of the servo motor must be centered to the axle rod adequately.
If the connecting line between the servo drive and motor exceeds 20 m (65.62 ft.), the UVW line
must be thickened. The connecting line of the encoder shall also be thickened.
The four set screws of the servo motor must be fastened.
2.2. Condition of the storage environment
The product must be placed in the packing box before installation. Pay attention to the following for
storage to make sure that the product condition is applicable to our warranty and future maintenance if
the drive wouldn't be used for the moment:
The product must be placed in a dustless and dry place.
The ambient temperature of the storage location must be kept within -20°C ~ +65°C (-4°F ~
149°F).
The relative humidity of the storage location must be kept within 0% and 90%without
condensation.
Do not store the product in the environment with corrosive gas or liquid.
The product should be packed properly and stored on the shelf or platform.
2.3. Condition of installation environment
Operating temperature:
ISA-7 series servo drive: 0°C ~ 55°C (32°F ~ 131°F)
ISA-7 series servo motor: 0°C ~ 40°C (32°F ~ 104°F)
The product must be placed in a well ventilated area if the ambient temperature exceeds 45°C. If the
product is placed in the distribution box, the size and ventilation of the distribution box must be able to
prevent the electronic device in the distribution box from overheating. Pay attention to see if the
machine vibration affects the electronic device of the distribution box.
Besides, the following must be observed for the selection of the installation location. If not, our server
product might not be applicable to our warranty and future maintenance:
Our server product can be installed in places without heat emitting device, water drop, steam,
dust, oil dust, corrosive or flammable gas or liquid, floating dust or metal particle. It can also be
installed in stable places without vibration or interference of electromagnetic noise.
Keep the temperature and humidity of the place where the servo drive and motor are installed
within the specified range.
Do not store the servo drive or motor in the place with the vibration exceeding the specified
degree.
Make sure that the servo drive and motor are stored in locations that conform to the
environmental specifications stated in our manual.
