3.3.4. User-specified DI and DO signals
If the desired DI/DO signal can't be found among the default ones, the user may set new DI/DO. The
function of the DI1~9 and DO1~6 signals depend on the parameters PC-01~PC-09 and PC-10~PC-15.
Refer to the following table. Input the DI or DO code in the corresponding parameter to set the
function of this DI/DO.
Signal Name
Pin No
Corresponding
parameter
Signal Name
Pin No
Corresponding
parameter
Standard
DI
DI1-
CN1-9
PC-01
Standard
DO
DO1+
CN1-7
PC-10
DI2-
CN1-10
PC-02
DO1-
CN1-6
DI3-
CN1-34
PC-03
DO2+
CN1-5
PC-11
DI4-
CN1-8
PC-04
DO2-
CN1-4
DI5-
CN1-33
PC-05
DO3+
CN1-3
PC-12
DI6-
CN1-32
PC-06
DO3-
CN1-2
DI7-
CN1-31
PC-07
DO4+
CN1-1
PC-13
DI8-
CN1-30
PC-08
DO4-
CN1-26
DI9
CN1-12
PC-09
DO5+
CN1-28
PC-14
DO5-
CN1-27
DO6+
CN1-16
PC-15
DO6-
CN1-15
