Lite-On Technology Corp.
Industrial Automation
229
11.3.4. Coordinate initialization by DI/DO
When DI(AENC_E) signal ON, and DI( AENC_C) signal change from OFF to ON, coordinate system
will be initialized. After initialization, absolute pulse value and PUU will be reset to zero. Please refer to
picture 11.3
Te(ms)
Tc(ms)
Min(ms)
PC-00+5
PC-00+20
Max(ms)
PC-00+200
N/A
