LiteOn ISA-7-040-S1 User Manual

Lite-On Technology Corp.
Industrial Automation
234
PD-61
(R-only)
APREV
Absolute encoder position-
pulses in a round or PUU
Communication address：
037AH
037BH
Initial value
0x00
Control mode
ALL
Unit
Pulse or PUU
Configuration range
0 ~ (131072-1) (Pulse)
-2147483648 ~ 2147483647
(PUU)
Data size
32bit
Data format
DEC
If PD-57 Bit1= 1, the absolute coordinate is pulse value, the parameter represents the pulse in a turn.
If PD-57 Bit1= 0, the absolute coordinate is PUU, the parameter is encoder absolute position PUU.
11.5. Digital input definition(absolute encoder function)
Name
DI code
Input function
AENC_E
0x10
Absolute encoder pin enable, refer to:
11.3.4 Initialization by DI/DO
11.3.6 Read absolute position by DI/DO
AENC_C
0x11
Absolute coordination reset, refer to:
11.3.4 Initialization by DI/DO
AENC_Q
0x12
Handshaking pin of data transmission, refer to:
11.3.6 Read absolute position by DI/DO
11.6. Digital output definition(absolute encoder function)
Name
DI code
Output function
AENC_D
0x0D
Absolute position output, refer to:
11.3.6 Read absolute position by DI/DO
AENC_E
RR
0x0E
Absolute system warning, refer to:
11.3.6 Read absolute position by DI/DO
11.7. Absolute System Alarm List
Alarm
indication
Alarm name
Description for alarm activation
Indication
DO
Switching of
servo state
AL030
Encoder over voltage
or internal error
Battery over voltage ( > 3.8V), or encoder
internal error.
ALM
Servo Off
AL033
Position lost
1. Coordinate is not initialized.
2. Absolute encoder position lost, due to low
battery or power interrupted.
WRN
Servo On
