Lite-On Technology Corp.
Industrial Automation
25
Installation notes:
1. Make sure that the power supply and wiring for the R S T and L1 and L2 must be accurate.
2. Make sure that the phase sequence regarding the wiring for the servo motor output U V W is
correct. The motor will not work if the connection is wrong and an alarm will occur.
3. When using the external regenerative resistor, open the circuit for the P and D ends and connect
the external regenerative resistor to the P and C ends. When using the internal external
regenerative resistor, short the circuit for the P and D ends and open the circuit for the P and C
ends.
If using the external braking unit, connect P+ and P- of the braking unit to the P and N ends of the
servo motor. Open the circuit for the P and D ends, as well as the P and C ends.
4. For the alarm or emergency stop, use ALM or WARN output to disconnect the magnetic
contactor (MC) to cut off the power supply of the servo drive.
