The description for the definition of each signal is as follows:
Connector end of the drive
Connector for the leadwire of the
encoder
Serial communication signal
input/output(-)
Serial communication signal
input/output(+)
Earth wire of the power supply
Refer to the following for the way to make the
the shield for the connector of the CN2
encoder:
(1) Weld the core wire of the metal mesh to the metal
part of the connector so that the connector is metal
shielded.
(2) Fit the connector into its case as illustrated.
(3) Fasten the case to complete the shielding.
