CHAPTER 7: GENERAL DESCRIPTION 7-11
ALPHA 552
3.2.3 Standard pusher (1596mm) with cone
Ø pusher
Øguiding
elements
Loading flag Connecting part to the loading flag Attach Pusher body Rotating sleeve Adapter Cone
A B C D E F G
10 11
G/Av : 052.015.124
D/Av : 052.015.184
- -
052.15.364/10
015.031.013/10 -
052.15.474/10
052.15.1064/10
11 12
G/Av : 052.015.124
D/Av : 052.015.184
- -
052.15.364/11
015.031.013/10 -
052.15.474/11
052.15.1064/11
12 13
G/Av : 052.015.124
D/Av : 052.015.184
- -
052.15.364/12
015.031.013/10 -
052.15.474/12
052.15.1064/12
13 14
G/Av : 052.015.114
D/Av : 052.015.174
- -
052.15.644
015.031.013/10 -
052.15.474/13
052.15.1064/13
14 15
G/Av : 052.015.114
D/Av : 052.015.174
- -
052.15.764
015.031.013/10 -
052.15.474/14
052.15.1064/14
15 16
G/Av : 052.015.114
D/Av : 052.015.174
- -
052.15.754/15
015.031.013/15 -
052.15.464/15
052.15.1054/15
16 17
G/Av : 052.015.114
D/Av : 052.015.174
- -
052.15.754/16
015.031.013/15
028.031.074 052.15.464/16
052.15.1044/16
17 18
G/Av : 052.015.114
D/Av : 052.015.174
- -
052.15.754/17
015.031.013/15 -
052.15.464/17
052.15.1054/17
18 19
G/Av : 052.015.104
D/Av : 052.015.164
052.015.214
015.031.013/15
028.031.104 052.15.464/18
052.15.1044/18
19 20
G/Av : 052.015.104
D/Av : 052.015.164
052.015.224
015.031.013/15 -
052.15.464/19
052.15.1054/19
20 21
G/Av : 052.015.104
D/Av : 052.015.164
052.015.234
015.031.013/15 -
052.15.454/20
052.15.1044/20
21 22
G/Av : 052.015.104
D/Av : 052.015.164
052.015.244
015.031.013/15 -
052.15.464/21
052.15.1054/21
22 23
G/Av : 052.015.104
D/Av : 052.015.164
052.015.254
015.031.013/15 -
052.15.454/22
052.15.1044/22
23 24
G/Av : 052.015.104
D/Av : 052.015.164
052.015.264
015.031.013/15 -
052.15.464/23
052.15.1054/23
24 25
G/Av : 052.015.104
D/Av : 052.015.164
052.015.274
015.031.013/15 -
052.15.464/24
052.15.1054/24
25 26
G/Av : 052.015.104
D/Av : 052.015.164
052.015.284
015.015.814
052.015.994 052.15.434/25
052.15.374/25
26 27
G/Av : 052.015.104
D/Av : 052.015.164
052.015.294
015.015.814 -
052.15.434/26
052.15.1024/26
27 28
G/Av : 052.015.104
D/Av : 052.015.164
052.015.304
015.015.814 -
052.15.434/27
052.15.1024/27
28 29
G/Av : 052.015.104
D/Av : 052.015.164
052.015.314
015.015.814
052.015.994 052.15.434/28
052.15.374/28
29 30
G/Av : 052.015.104
D/Av : 052.015.164
052.015.324
015.015.814 -
052.15.434/29
052.15.1024/29
30 31
G/Av : 052.015.104
D/Av : 052.015.164
052.015.334
015.015.814 -
052.15.434/30
052.15.1024/30
31 32
G/Av : 052.015.104
D/Av : 052.015.164
052.015.344
015.015.814 -
052.15.434/31
052.15.1024/31
32 33
G/Av : 052.015.104
D/Av : 052.015.164
052.015.354
015.015.814 -
052.15.434/32
052.15.1024/32
33 34
G/Av : 052.015.104
D/Av : 052.015.164
052.015.364
015.015.814 -
052.15.434/33
052.15.1024/33
34 35
G/Av : 052.015.104
D/Av : 052.015.164
052.015.374
015.015.814 -
052.15.444
052.15.1034
35 36
G/Av : 052.015.104
D/Av : 052.015.164
052.015.384
015.015.814 -
052.15.434/35
052.15.1024/35
36 37
G/Av : 052.015.094
D/Av : 052.015.154
052.015.394
014.021.013
052.015.1024 052.15.424/36
052.15.494/36
37 38
G/Av : 052.015.094
D/Av : 052.015.154
052.015.404
014.021.013 -
052.15.424/37
052.15.1014/37
38 39
G/Av : 052.015.094
D/Av : 052.015.154
052.015.414
014.021.013
052.015.1024 052.15.424/38
052.15.494/38
39 40
G/Av : 052.015.094
D/Av : 052.015.154
052.015.424
014.021.013 -
052.15.424/39
052.15.1014/39
40 41
G/Av : 052.015.094
D/Av : 052.015.154
052.015.434
014.021.013 -
052.15.424/40
052.15.1014/40
41 42
G/Av : 052.015.094
D/Av : 052.015.154
052.015.444
014.021.013 -
052.15.424/41
052.15.1014/41
42 43
G/Av : 052.015.094
D/Av : 052.015.154
052.015.454
014.021.013 -
052.15.424/42
052.15.1014/42
43 44
G/Av : 052.015.094
D/Av : 052.015.154
052.015.464
014.021.013 -
052.15.424/43
052.15.1014/43
44 45
G/Av : 052.015.094
D/Av : 052.015.154
052.015.474
014.021.013 -
052.15.424/44
052.15.1014/44
45 46
G/Av : 052.015.094
D/Av : 052.015.154
052.015.484
014.021.013 -
052.15.424/45
052.15.1014/45
48 49
G/Av : 052.015.094
D/Av : 052.015.154
052.015.514
014.021.013 -
052.15.424/48
052.15.1014/48
50 51
G/Av : 052.015.094
D/Av : 052.015.154
052.015.534
014.021.013 -
052.15.424/50
052.15.1014/50
52 53
G/Av : 052.015.094
D/Av : 052.015.154
052.015.554
014.021.013 -
052.15.424/52
052.15.1014/52
