7-12 CHAPTER 7: GENERAL DESCRIPTION
ALPHA 552
3.2.4 Long pusher (1876mm) with cone
Ø pusher
Ø guiding
elements
Loading flag
Connecting part to
the loading flag
Attach Pusher body Rotating sleeve Adapter cone
A B C D E F G
10
11
G/Av : 052.015.124
D/Av : 052.015.184
- -
052.15.1124/10
015.031.013/10 -
052.15.474/10
052.15.1064/10
11
12
G/Av : 052.015.124
D/Av : 052.015.184
- -
052.15.1124/11
015.031.013/10 -
052.15.474/11
052.15.1064/11
12
13
G/Av : 052.015.124
D/Av : 052.015.184
- -
052.15.1124/12
015.031.013/10 -
052.15.474/12
052.15.1064/12
13
14
G/Av : 052.015.114
D/Av : 052.015.174
- -
052.15.1134
015.031.013/10 -
052.15.474/13
052.15.1064/13
14
15
G/Av : 052.015.114
D/Av : 052.015.174
- -
052.15.1144
015.031.013/10 -
052.15.474/14
052.15.1064/14
15
16
G/Av : 052.015.114
D/Av : 052.015.174
- -
052.15.1154/15
015.031.013/15 -
052.15.464/15
052.15.1054/15
16
17
G/Av : 052.015.114
D/Av : 052.015.174
- -
052.15.1154/16
015.031.013/15
028.031.074 052.15.464/16
052.15.1044/16
17
18
G/Av : 052.015.114
D/Av : 052.015.174
- -
052.15.1154/17
015.031.013/15 -
052.15.464/17
052.15.1054/17
18
19
G/Av : 052.015.104
D/Av : 052.015.164
052.015.1304
015.031.013/15
028.031.104 052.15.464/18
052.15.1044/18
19
20
G/Av : 052.015.104
D/Av : 052.015.164
052.015.1314
015.031.013/15 -
052.15.464/19
052.15.1054/19
20
21
G/Av : 052.015.104
D/Av : 052.015.164
052.015.1324
015.031.013/15 -
052.15.454/20
052.15.1044/20
21
22
G/Av : 052.015.104
D/Av : 052.015.164
052.015.1334
015.031.013/15 -
052.15.464/21
052.15.1054/21
22
23
G/Av : 052.015.104
D/Av : 052.015.164
052.015.1344
015.031.013/15 -
052.15.454/22
052.15.1044/22
23
24
G/Av : 052.015.104
D/Av : 052.015.164
052.015.1354
015.031.013/15 -
052.15.464/23
052.15.1054/23
24
25
G/Av : 052.015.104
D/Av : 052.015.164
052.015.1364
015.031.013/15 -
052.15.464/24
052.15.1054/24
25
26
G/Av : 052.015.104
D/Av : 052.015.164
052.015.1374
015.015.814
052.015.994 052.15.434/25
052.15.374/25
26
27
G/Av : 052.015.104
D/Av : 052.015.164
052.015.1384
015.015.814 -
052.15.434/26
052.15.1024/26
27
28
G/Av : 052.015.104
D/Av : 052.015.164
052.015.1394
015.015.814 -
052.15.434/27
052.15.1024/27
28
29
G/Av : 052.015.104
D/Av : 052.015.164
052.015.1404
015.015.814
052.015.994 052.15.434/28
052.15.374/28
29
30
G/Av : 052.015.104
D/Av : 052.015.164
052.015.1414
015.015.814 -
052.15.434/29
052.15.1024/29
30
31
G/Av : 052.015.104
D/Av : 052.015.164
052.015.1424
015.015.814 -
052.15.434/30
052.15.1024/30
31
32
G/Av : 052.015.104
D/Av : 052.015.164
052.015.1434
015.015.814 -
052.15.434/31
052.15.1024/31
32
33
G/Av : 052.015.104
D/Av : 052.015.164
052.015.1444
015.015.814 -
052.15.434/32
052.15.1024/32
33
34
G/Av : 052.015.104
D/Av : 052.015.164
052.015.1454
015.015.814 -
052.15.434/33
052.15.1024/33
34
35
G/Av : 052.015.104
D/Av : 052.015.164
052.015.1464
015.015.814 -
052.15.444
052.15.1034
35
36
G/Av : 052.015.104
D/Av : 052.015.164
052.015.1474
015.015.814 -
052.15.434/35
052.15.1024/35
36
37
G/Av : 052.015.094
D/Av : 052.015.154
052.015.1484
014.021.013
052.015.1024 052.15.424/36
052.15.494/36
37
38
G/Av : 052.015.094
D/Av : 052.015.154
052.015.1494
014.021.013 -
052.15.424/37
052.15.1014/37
38
39
G/Av : 052.015.094
D/Av : 052.015.154
052.015.1504
014.021.013
052.015.1024 052.15.424/38
052.15.494/38
39
40
G/Av : 052.015.094
D/Av : 052.015.154
052.015.1514
014.021.013 -
052.15.424/39
052.15.1014/39
40
41
G/Av : 052.015.094
D/Av : 052.015.154
052.015.1524
014.021.013 -
052.15.424/40
052.15.1014/40
41
42
G/Av : 052.015.094
D/Av : 052.015.154
052.015.1534
014.021.013 -
052.15.424/41
052.15.1014/41
42
43
G/Av : 052.015.094
D/Av : 052.015.154
052.015.1544
014.021.013 -
052.15.424/42
052.15.1014/42
43
44
G/Av : 052.015.094
D/Av : 052.015.154
052.015.1554
014.021.013 -
052.15.424/43
052.15.1014/43
44
45
G/Av : 052.015.094
D/Av : 052.015.154
052.015.1564
014.021.013 -
052.15.424/44
052.15.1014/44
45
46
G/Av : 052.015.094
D/Av : 052.015.154
052.015.1574
014.021.013 -
052.15.424/45
052.15.1014/45
46
47
G/Av : 052.015.094
D/Av : 052.015.154
052.015.1584
014.021.013 -
052.15.424/46
052.15.1014/46
47
48
G/Av : 052.015.094
D/Av : 052.015.154
052.015.1594
014.021.013 -
052.15.424/47
052.15.1014/47
48
49
G/Av : 052.015.094
D/Av : 052.015.154
052.015.1604
014.021.013 -
052.15.424/48
052.15.1014/48
50
51
G/Av : 052.015.094
D/Av : 052.015.154
052.015.1624
014.021.013 -
052.15.424/50
052.15.1014/50
52
53
G/Av : 052.015.094
D/Av : 052.015.154
052.015.1644
014.021.013 -
052.15.424/52
052.15.1014/52
