1.4.7. PLC inputs / outputs
Inputs Outputs
Input Des. Description Output Des. Description
I0 K8 Safety relay O32 YV1A Lower loading table
I1 SP1 Air pressure switch O33 YV1B Raise loading table
I2 SQ10 Main cover safety O34 KA1 Motor M2 up
I3 SQ11 Loading magazine grid safety O35 KA2 Motor M2 down
I4 SQ12 Retraction safety switch O36 SON Servo motor ON
I5 -
Not in use
O37 -
Not in use
I6 -
Not in use
O38 YV3 Guiding profiled bar (option)
I7 -
Not in use
O39 -
Not in use
I8 SQ1 Loading table in lower position O40 YV2 Telescopic pusher (option)
I9 SQ2 Loading table in upper position O41 -
Not in use
I10 SQ3 Measuring cell O42 -
Not in use
I11 SQ4 Diameter adjustment O43 -
Not in use
I12 SQ5 Pusher in home position O44 -
Not in use
I13 SQ30 Loading magazine empty (option) O45 -
Not in use
I14 SQ31 Telescopic pusher (option) O46 -
Not in use
I15 -
Not in use
O47 KS Start relay
I16 -
Not in use
O48 -
Not in use
I17 -
Not in use
O49 -
Not in use
I18 -
Not in use
O50 -
Not in use
I19 -
Not in use
O51 -
Not in use
I20 -
Not in use
O52 -
Not in use
I21 -
Not in use
O53 -
Not in use
I22 -
Not in use
O54 -
Not in use
I23 -
Not in use
O55 -
Not in use
Interface Interface
I24 A1 Clamping device signal - -
Not in use
I25 A2 Lathe in auto cycle - -
Not in use
I26 A3 Feed order - -
Not in use
I27 A4 Push order - -
Not in use
I28 A.. Programmable interface input - -
Not in use
I29 A.. Programmable interface input - -
Not in use
I30 A.. Programmable interface input - -
Not in use
I31 A.. Programmable interface input - -
Not in use
