CHAPTER 7: OPERATION 7-5
QUICK LOAD SERVO III MI
Switch between normal feed rate and
slow feed rate (only in manual mode) for
added positioning accuracy
Automatic Top-Cut positioning in manual
mode
(picture may be reversed)
Validate
Teach data
Cancel
Offset correction
Confirm. In setup mode, the button
must be hold for 3 seconds to
validate the change.
Increment data in offset correction mode
Start sequence
Decrement data in offset correction mode
Enter the loading table calibration mode
Lower the loading table (in calibration mode)
Rise the loading table (in calibration
mode)
