Logik L17LID648

10
13
12
14
16
18
15
17
19
20
21
LCD TV
SIDE VIEW
12) COMMON INTERFACE slot
13)
/ I button
 Turnstheunitonandoff.
14) PLAY button
 Presstostartorresumeplaybackofadisc.
15) MENU button
 Presstodisplaytheon-screenTVmenu.
16) FUNCTION button
 SelectDTV,TV,AV1,AV2/SCART,YUV/SCART,
DVDorHDMI.
17) CH buttons
 Presstochange the TV channels andhighlight
selections(Up&Down)onthemenuscreen.

button
 Presstoselectprevioustitle,chapterortrackon
adisc.

button
 Press to select next title, chapter or track on a
disc.
18) + VOL – controls
 Adjustthevolumelevel.
19) Disc Door
 Pushgentlytoclosethediscdoor.
20) button
 Presstoopenthediscdoor.
21) Removable Stand
