CONNECTING A TV AERIAL/CABLE/SATELLITE
To view television channels correctly, a signal must be
receivedfromoneofthefollowingsources:
-Anindoororoutdooraerial
-Acablesystem
-Asatellitesystem
Note:
Forreceivingover-the-airTVbroadcasts,werecommend
thatyouuseanexternalxedaerial.Shouldyourequire
the use of a temporary aerial, please ensure that you
purchaseanaerialwithsufcientabilitytoreceiveinweak
signalareas. Onlywhen youareincloseproximitytoa
transmitterwillatemporaryaerialreproduceasignalas
stronglyasaxedaerial.
CONNECTING A POWER CORD
• ConnecttheACpowercordintoawalloutlet.
• Pressthe / Ibuttonontheunitorremotecontrolto
turnontheunit.
Note:
• BesuretheACpowercordisdisconnectedandtheTV
isswitchedoffbeforemakingconnections.
• Make sure that all the components are connected
correctly.
• Whenyouarenotgoingtousetheunitforalongperiod
oftime,disconnectthepowercord.
• The apparatus should not be exposed to dripping or
splashingandthatnoobjectslledwithliquids,suchas
vases,shouldbeplacedonapparatus.
• Themainsplug is usedasthe disconnecting device.
Itshouldremainreadilyaccessibleandshouldnotbe
obstructedduringuse.Tobecompletelydisconnectedfromthesupplymains,themainsplugoftheapparatus
shouldbedisconnectedfromthemainssocketoutletcompletely.
CONNECTIONS
COMMON INTERFACE
TheunitisequippedwithaCIslot.TheCIslotallowsyoutoinsertaCAM(ConditionalAccessModule)withan
appropriatesubscriptioncardforsomepayforviewservices.
It is required to subscribe to a pay channel company to view the pay channels of the Digital Terrestrial
broadcasting.
FullyinserttheCAM(ConditionalAccessModule)intotheCI(CommonInterface)slotonthebottomoftheunit
withitslabelsidefacingyou.
Important notes:
• SwitchofftheTVandunplugfromtheACpowermainsbeforeinsertorremovetheCAM.
• TheCAMshouldbecorrectlyinserted,itisimpossibletoinsertfullyifreversed.TheCAMortheTV
terminal may be damaged if the CAM is forcefully inserted.
• Some CAMs may require setting up. Refer to the module instruction manual for details of the
settings.
PREPARATION
CONNECTIONS USING THE FEATURES SPECIFICATIONTROUBLESHOOTING
USING THE DVD
FEATURES
PREPARATIONCONNECTIONSUSING THE FEATURES
USING THE DVD
FEATURES
TROUBLESHOOTINGSPECIFICATION
Satellite, Cable, or TV aerial cable
to TV AERIAL CABLE Terminal
(cable not included)
TV
AERIAL
