Logik L17LID648 User Manual

9
1 2 3
4) Power Cord
5) PHONES jack
6) DVD VIDEO OUT jack
7) HDMI in jack
8) SCART jack (AV IN 2)
9) VIDEO IN jack (AV IN 1)
10) AUDIO IN jacks (Left/Right)
(AV IN 1)
11) TV Aerial port
LCD TV
FRONT VIEW
BACK VIEW
1) Speakers
2) Remote Sensor/ Standby
Indicator

 •IndicateswhethertheunitisONorin
 STANDBY(OFF)mode.
   •AmberRedLightOn:
   TheunitisinSTANDBY.
   •AmberRedLightOff:
   TheunitisturnedON.
 • Donotblockthissensorortheremote
controlwillnotworkproperly.
3) Colour LCD Screen
7 910 1186
4
5
PREPARATION
CONNECTIONS USING THE FEATURES SPECIFICATIONTROUBLESHOOTING
USING THE DVD
FEATURES
PREPARATIONCONNECTIONSUSING THE FEATURES
USING THE DVD
FEATURES
TROUBLESHOOTINGSPECIFICATION
