Logik L17LID648 User Manual

16
DolbyDigitalisasoundsystemdevelopedbyDolbyLaboratoriesInc.Thisunitautomaticallyrecognizes
DVDsthathavebeenrecordedwithDolbyDigital.
NotallDolbyDigitalsourcesarerecordedwith6channels.
SomesourcesmarkedDolbyDigitalmayberecordedinDolbySurround,a2channelsystem.Lookfor
thislogoonyourunit.
ManufacturedunderlicensefromDolbyLaboratories.
‘Dolby’andthedouble-DsymbolaretrademarksofDolbyLaboratories.
DOLBY DIGITAL (FOR DVD)
USING HEADPHONES
• Turn down the volume before connecting
headphonestotheunit,thenadjustthevolume
toyourdesiredlevel.
• When headphones are connected, no sound
willcomefromthefrontspeakers.
Note:
• Avoid listening to sound at high levels for
prolongedperiodsoftime.Thismaybeharmful
toyouandmaycausehearingloss.
Earphones / Headphones
(1/8”[3.5mm]diameterplug)
CONNECTING HDMI
HDMI(HighDenitionMultimediaInterface)supportsbothvideoandaudioonasingledigitalconnection
forusewithDVDplayers,DTV,set-topboxesandotherdigitalAVdevices.HDMIwasdevelopedto
providethetechnologiesofHighBandwidthDigitalContentProtection(HDCP)aswellasDigitalVisual
Interface(DVI)inonespecication.HDCPisusedtoprotectdigitalcontenttransmittedandreceived
byDVI-compliantorHDMI-compliantdisplays.
HDMIhasthecapabilitytosupportstandard,enhancedorhigh-denitionvideoplusstandardtomulti-
channelsurround-soundaudio.HDMIfeatureincludeuncompresseddigitalvideo,oneconnector(instead
ofseveralcablesandconnectors),andcommunicationbetweentheAVsourceandAVdevicessuch
asDTVs.
CONNECTIONS
HDMI, the HDMI logo  and High-
DenitionMultimediaInterfacearetrademarksor
registeredtrademarksofHDMIlicensingLLC.
Connect the HDMI cable (not included) as
shown.
Make sure you connect the cable from the
equipment(HDMI OUT)tothisunit(HDMI IN).
To operate the connected device and play the
source,rstpresstheFUNCTIONbuttontoselect
theHDMImode.
ToHDMI
OUTjack
ToHDMIIN
jack
