Lorex LNR110 Series User Manual

LNR110 Series Hard Drive Installation
19
4. Turn the NVR back over and remove the cover. The easiest way to do this is to pull up
on the edge that hangs over the rear panel of the unit.
5. Place the hard drive over the screw slots on the bottom of the NVR and then slide the
hard drive into place. The SATA connectors on the hard drive should face the front of
the unit.
6. Connect the SATA power and data cable to the hard drive.
#LX400070; r. 1.0/27147/27147; en-US
