LNR110 Series System
Specifications
22
22.1 System
Operating System
Embedded LINUX
Pentaplex
Simultaneous View, Record, Playback, Backup,
and Remote Monitoring
Number of Channels 4/8 Channels
22.2 Inputs/Outputs
Video IN 4/8 ch: PoE Video Input
Video OUT Yes, 1 VGA & 1 HDMI
VGA OUT Yes
HDMI Yes
Audio IN
1 Line IN (RCA) for two-way audio
Audio OUT 1 Line OUT (RCA) for two-way audio
USB Port 1 at the back, 1 at the front
Alarm IN No
Alarm OUT No
Video Output Resolution
1920×1080, 1280×1024, 1280×720, 1024×768,
800x600
PTZ Control
Lorex IP PTZ cameras only
22.3 Display
Display Split 4 ch: 1/4
8 ch: 1/4/8/9
Live Display Speed 4 ch: 120 NTSC, 100 PAL
8 ch: 240 NTSC, 200 PAL
OSD Camera Title, Time, Camera Lock, Motion Detec-
tion, Recording Status
System Navigation USB mouse
Motion Area Setting Adjustable grid (22x18)
Sensitivity Levels
100
Firmware Upgrade Automatic over the Internet & via USB device and
network
User Authority By user group
Time Synchronization
Auto time sync by NTP server
22.4 Recording
Compression H.264
Resolution 1080P (1920×1080) / 720P (1280×720)
Record Rate 120FPS @ 1080P / 240FPS @ 720P
Recording Resolution Setting Per camera for different resolutions
Recording Quality Control 6 levels
Record Schedule
By hour, by day, by recording mode, by motion, by
channel
#LX400070; r. 1.0/27147/27147; en-US
171
