Lorex LNR110 Series - Step 3: Connect the Ethernet Cable; Step 4: Connect the Monitor; Step 5: Connect the Power Adapter to Power the NVR

Basic Setup (LNR110 Series)
6
6.3 Step 3: Connect the Ethernet Cable
• Connect an Ethernet cable (included) to the LAN port on the rear panel of the system.
Connect the other end of the Ethernet cable to a router on your network.
6.4 Step 4: Connect the Monitor
• Connect the included HDMI cable from the HDMI port to the TV or monitor
(recommended).
OR
• Connect a VGA cable (not included) from the VGA port to the monitor.
1. HDMI port.
2. VGA port.
6.5 Step 5: Connect the Power Adapter to Power the NVR
• Connect the included AC power adapter to the NVR and connect the other end to a
power outlet or surge protector.
#LX400070; r. 1.0/27147/27147; en-US
