Lorex LW2003 User Manual

19
6. Using the Baby Monitor
6.10 POWER SAVE (AUDIO ONLY MODE)
Power Save mode allows the monitor display to be turned off while
continuing audio monitoring. You will still be able to listen to your
cameras during Power Save mode. Press any button to turn the display
back on.
To enable Power Save mode:
1. Press the MENU button.
2. Press
oruntil you select .
3. Press orto change the duration
of how long the monitor display remains
on before turning off.
4. Press the MENU button to exit and save
y
our settings.
After the selected duration (i.e. 15
seconds), the monitor’s display turns of
f.
The monitor will continue to broadcast
audio.
Press any button on the monitor to power
the display. The displays shuts off after the
pre-set period of time.
Note:
• It is not recommended to use VOX and P
ower Save mode at the same
time.
• The Power Save feature can extend monitor battery life up to 25%.
1 min

Lorex LW2003 Specifications

General Specifications

transmission frequency	ISM 2, 400~2, 482 MHz
transmission power	18 dBm
unobstructed effective range	150 m / 450 ft
spread spectrum	FHSS
modulation mode	GFSK
operating temperature	0-50ºC / 32-122ºF
operating humidity	Less than 90%

Camera Specifications

imaging sensor type	CMOS
picture total pixels	H:240, V:320
minimum illumination	0 Lux (IR on)
night video distance	7 m / 22 ft
view angle	H: 38º V: 50º
image resolution	240 x 320 up to 25 fps
consumption current (max.)	390 mA
power supply	5 V DC
dimensions (W x D x H)	66 x 95 x 115 mm / 2.6 x 3.8 x 4.6"
weight	0.25 kg / 0.5 lbs

Receiver Specifications

LCD screen type	2.4 “ TFT-LCD
effective pixels	H: 240, V:320
receiving sensitivity	<.81 dBm
consumption current (max.)	250 mA
power supply	5 V DC
dimensions (W x D x H)	48 x 17 x 117 mm / 1.9 x 0.7 x 4.6"
weight	0.14 kg / 0.3 lbs

Product Information

package dimensions (LW2003)	199 x 69 x 135 mm / 7.8 x 2.7 x 5.3"
package cube (LW2003)	0.0025 cbm / 0.09 cbf
package weight (LW2003)	0.7 kg / 1.5 lbs
package dimensions (LW2003F)	200 x 69 x 139 mm / 7.9 x 2.7 x 5.5"
package cube (LW2003F)	0.0025 cbm / 0.09 cbf
package weight (LW2003F)	0.7 kg / 1.5 lbs
